CE FN92XX-Inlet

Excellent Performance EMC/RFI Filter with Earth Line Choke

Rated currents up to 15 A
Superior attenuation performance
Integrated earth line choke
Complies with IEC/EN 60601-1
Snap-in versions (S and S1 type)
Hot inlet versions (HI type)

Articles

Article	Rated Current @ambient	Leakage current IEC60939	Inductance		Capacitance		Resistance	Distribution stock	Compare	Read More
Article	Rated Current @ambient	Leakage current IEC60939	L1	L2	Cx1 (µF)	Cy1 (nF)	Resistance	Distribution stock	Compare	Read More
FN9244ES-3-06	3	0.31	13.45	0.4	0.1	2.2
FN9244EB-10-06	10	0	1.02	0.4	0.1		1000
FN9244EB-12-06	12	0	0.58	0.1	0.1		1000
FN9244EB-12-06HI	12	0	0.58	0.1	0.1		1000
FN9244ER-3-06	3	0.31	13.45	0.4	0.1	2.2	1000
FN9244ER-6-06	6	0.31	4.1	0.4	0.1	2.2	1000
FN9244ER-8-06	8	0.31	2.3	0.4	0.1	2.2	1000
FN9244ER-10-06	10	0.31	1.02	0.4	0.1	2.2	1000
FN9244ER-12-06	12	0.31	0.58	0.1	0.1	2.2	1000
FN9244ER-12-06HI	12	0.31	0.58	0.1	0.1	2.2	1000
FN9244ES-1-06	1	0.31	59.54	0.4	0.1	2.2
FN9244EB-8-06	8	0	2.3	0.4	0.1		1000
FN9244ES-6-06	6	0.31	4.1	0.4	0.1	2.2
FN9244ES-8-06	8	0.31	2.3	0.4	0.1	2.2
FN9244ES-10-06	10	0.31	1.02	0.4	0.1	2.2
FN9244ES-12-06	12	0.31	0.58	0.1	0.1	2.2
FN9244ES-15-06	15	0.31	0.4	0.1	0.1	2.2
FN9244ES1-1-06	1	0.31	59.53	0.4	0.1	2.2
FN9244ES1-3-06	3	0.31	13.45	0.4	0.1	2.2
FN9244ES1-6-06	6	0.31	4.1	0.4	0.1	2.2
FN9244ES1-8-06	8	0.31	2.3	0.4	0.1	2.2
FN9244ER-15-06HI	15	0.31	0.4	0.1	0.1	2.2	1000
FN9244E-1-06	1	0.31	59.53	0.4	0.1	2.2
FN9244E-6-06	6	0.31	4.1	0.4	0.1	2.2
FN9244E-8-06	8	0.31	2.3	0.4	0.1	2.2
FN9244E-15-06	15	0.31	0.4	0.1	0.1	2.2
FN9244E-15-06HI	15	0.31	0.4	0.1	0.1	2.2
FN9244EB-1-06	1	0	59.53	0.4	0.1		1000
FN9244EB-15-06	15	0	0.4	0.1	0.1		1000
FN9244EB-15-06HI	15	0	0.4	0.1	0.1		1000
FN9244ER-1-06	1	0.31	59.53	0.4	0.1	2.2	1000
FN9244ER-15-06	15	0.31	0.4	0.1	0.1	2.2	1000
FN9244ES1-10-06	10	0.31	1.02	0.4	0.1	2.2
FN9244EU-1-06	1	0.31	59.53	0.4	0.1	2.2
FN9244EU-15-06	15	0.31	0.4	0.1	0.1	2.2
FN9244EU-15-06HI	15	0.31	0.4	0.1	0.1	2.2
FN9244E-3-06	3	0.31	13.45	0.4	0.1	2.2
FN9244E-10-06	10	0.31	1.02	0.4	0.1	2.2
FN9244E-12-06	12	0.31	0.58	0.1	0.1	2.2
FN9244E-12-06HI	12	0.31	0.58	0.1	0.1	2.2
FN9244EB-3-06	3	0	13.45	0.4	0.1		1000
FN9244EB-6-06	6	0	4.1	0.4	0.1		1000
FN9244EU-3-06	3	0.31	13.45	0.4	0.1	2.2
FN9244ESR-10-06	10	0.31	1.02	0.4	0.1	2.2	1000
FN9244ESR-12-06	12	0.31	0.58	0.1	0.1	2.2	1000
FN9244ESR-15-06	15	0.31	0.4	0.1	0.1	2.2	1000
FN9244ES1R-1-06	1	0.31	59.53	0.4	0.1	2.2	1000
FN9244ES1R-3-06	3	0.31	13.45	0.4	0.1	2.2	1000
FN9244ES1R-6-06	6	0.31	4.1	0.4	0.1	2.2	1000
FN9244ES1R-8-06	8	0.31	2.3	0.4	0.1	2.2	1000
FN9244ES1R-10-06	10	0.31	1.02	0.4	0.1	2.2	1000
FN9244ES1R-12-06	12	0.31	0.58	0.1	0.1	2.2	1000
FN9244ES1R-15-06	15	0.31	0.4	0.1	0.1	2.2	1000
FN9244ESR-8-06	8	0.31	2.3	0.4	0.1	2.2	1000
FN9244EU-6-06	6	0.31	4.1	0.4	0.1	2.2
FN9244EU-8-06	8	0.31	2.3	0.4	0.1	2.2
FN9244EU-10-06	10	0.31	1.02	0.4	0.1	2.2
FN9244EU-12-06	12	0.31	0.58	0.1	0.1	2.2
FN9244EU-12-06HI	12	0.31	0.58	0.1	0.1	2.2
FN9244ESB-6-06-20	6	0	4.1	0.4	0.1		1000
FN9244EA-10-06	10	0.07	1.02	0.4	0.1	2.2
FN9244ESR-3-06-20	3	0.31	13.45	0.4	0.1	2.2	1000
FN9244ESR-10-06-20	10	0.31	1.02	0.4	0.1	2.2	1000
FN9244ES1B-1-06	1	0	59.53	0.4	0.1		1000
FN9244ES1-12-06	12	0.31	0.58	0.1	0.1	2.2
FN9244ES1-15-06	15	0.31	0.4	0.1	0.1	2.2
FN9244ESB-1-06	1	0	59.54	0.4	0.1		1000
FN9244ESB-3-06	3	0	13.45	0.4	0.1		1000
FN9244ESB-6-06	6	0	4.1	0.4	0.1		1000
FN9244ESB-8-06	8	0	2.3	0.4	0.1		1000
FN9244ESB-10-06	10	0	1.02	0.4	0.1		1000
FN9244ESB-12-06	12	0	0.58	0.1	0.1		1000
FN9244ESB-15-06	15	0	0.4	0.1	0.1		1000
FN9244ESB-10-06-20	10	0	1.02	0.4	0.1		1000
FN9244ES1B-3-06	3	0	13.45	0.4	0.1		1000
FN9244ES1B-6-06	6	0	4.1	0.4	0.1		1000
FN9244ES1B-8-06	8	0	2.3	0.4	0.1		1000
FN9244ES1B-10-06	10	0	1.02	0.4	0.1		1000
FN9244ES1B-12-06	12	0	0.58	0.1	0.1		1000
FN9244ES1B-15-06	15	0	0.4	0.1	0.1		1000
FN9244ESR-1-06	1	0.31	59.54	0.4	0.1	2.2	1000
FN9244ESR-3-06	3	0.31	13.45	0.4	0.1	2.2	1000
FN9244ESR-6-06	6	0.31	4.1	0.4	0.1	2.2	1000

Features and Benefits

Superior conducted attenuation performance, based on chokes with high saturation resistance and excellent thermal behavior

Rear/front or snap-in mounting

Without earth line choke see FN 9244 data sheet

FN 9244 B versions comply with the requirements of 1MOP acc. to IEC/EN 60601-1 for creepage and clearance, leakage current and high potential testing

Wide mounting flanges available

Custom-specific versions are available on request

Typical Applications

Electrical and electronic equipment

Small to medium-sized machines and household equipment

Single-phase power supplies, switch-mode power supplies

Test and measurement equipment

Medical devices (MDD)

In-vitro diagnostic medical devices (IVDD)

Rack mounting equipment

Technical Specifications

Maximum continuous operating voltage

250 VAC, 50/60 Hz

Nominal operating voltage

230 VAC

Rated currents

1 to 15 A @ 50°C

Operating frequency

DC to 400 Hz

High potential test voltage

P –> PE 2000 VAC for 2 sec (standard types)

P –> PE 2500 VAC for 2 sec (B types)

P –> N 1000 VAC for 2 sec

Temperature range (operation and storage)

-25°C to +85°C (25/85/21)

Protection category

IP 40 according to IEC 60529

Flammability corresponding to

Plastic material: UL 94 V0

Approvals by rated current

1 to 10 A (ENEC, CQC)

1 to 15 A (UL, CSA)

Design corresponding to

UL 1283, CSA 22.2 No. 8 1986, IEC/EN 60939

MTBF (Mil-HB-217F)

>2,230,000 h @ 50°C/230 V

Typical electrical schematic
